代碼:

1. #ifndef _TM1638_H_

2. #define _TM1638_H_

3.

4. #include "stm32f10x.h"

5.

6. typedef enum { N = 0x00, Y = 0x80} PointState; //是否帶小數點 Y：帶，N：不帶

7.

8. typedef enum { OFF = 0x00, ON = 0x01} LightState; //燈開關狀態 On：開，Off：關

9.

10. //TM1638模塊相關引腳定義

11. #define STB GPIO_Pin_5

12. #define CLK GPIO_Pin_6

13. #define DIO GPIO_Pin_7

14. #define GPIO_TM1638 GPIOA

15. #define GPIO_Pin_TM1638 STB|CLK|DIO

16. #define RCC_TM1638 RCC_APB2Periph_GPIOA

17.

18. //引腳高低電平設置

19. #define STB_0() GPIO_ResetBits(GPIO_TM1638,STB)

20. #define STB_1() GPIO_SetBits(GPIO_TM1638,STB)

21.

22. #define CLK_0() GPIO_ResetBits(GPIO_TM1638,CLK)

23. #define CLK_1() GPIO_SetBits(GPIO_TM1638,CLK)

24.

25. #define DIO_0() GPIO_ResetBits(GPIO_TM1638,DIO)

26. #define DIO_1() GPIO_SetBits(GPIO_TM1638,DIO)

27.

28. #define DIO_Read() GPIO_ReadInputDataBit(GPIO_TM1638,DIO)

29.

30. //用戶層函數

31. void TM1638_Init(void); //TM1638初始化函數

32. void TM1638_Display_Num(u32 data); //顯示數字

33. void TM1638_Display_SEG(unsigned int num,unsigned char seg,PointState p); //選擇數碼管顯示0-F

34. void TM1638_Display_LED(unsigned int num,LightState light); //指定led亮滅

35.

36. unsigned char TM1638_ReadKey(void); //TM1638讀鍵掃數據函數

37. void TM1638_SEG_Off(unsigned char num);  //TM1638關閉指定數碼管函數

38. void TM1638_Clear(void); //TM1638全清

39.

40. //底層函數

41. void TM1638_Write_Byte(u8 byte); //TM1638單寫數據，需要在函數外對STB操作

42. void TM1638_Write_Data(u8 data); //TM1638一個完整數據寫入

43. void TM1638_Write_Addr_Bond(u8 addr,u8 data); //TM1638指定地址寫入數據

44. unsigned char TM1638_Read(void); //TM1638讀數據函數

45. void TM1638_GPIO_Init(void); //TM1638引腳初始化函數

46.
